OD Series  Connectronics Outdoor Enclosure
The OD series outdoor enclosure is the ultimate choice for your outdoor racking requirements. Being made of Alumiflex™ you’ll find it noticeably lighter than steel, yet strong enough to rack even the heaviest equipment. The OD series enclosures are available in NEMA 3R (vented), 4 (with closed loop AC), or 4X (with closed door AC and anti-corrosion option, painted) configurations. The additional Alumishield™ (sun roof), provides superior solar protection with it’s large overhang roof design.
The versatile strut system allows you to position the racking rails at any depth desired within the enclosure. You can rest assured your equipment is safe and secure as you pad lock the front and rear door handles, knowing they hold the three points locking system securely intact. The OD series enclosures are available in various heights and depths and are designed to accommodate the weather protection of your choice. They are also available in dual and triple bay versions as well.

Standard Features
-  Includes front and back locking doors
   (padlock handles)
-  19" EIA rack spacing is standard

RAILS: 1 set with 25" depth, 2 sets with 34" and 42"
(see accessories for addtional rails).

A: Select enclosure size;
B: Select Option Group appropriate for the environment
      and the enclosure size.
These are single bay sizes - there are many more sizes available. Call us for other sizes and options

Top Level Part Number   Base  Size
H" x W" x D"
Suggested
Option Group
(see codes below)
CLICK TO ENLARGE
(xx=Option Code
(see codes below)
Depth Finish DDB Part No.
16" High Enclosures
19-3040Axx 25" Aluminum OD-16DX 16 x 26 x 25 01, 02, 04, 05 OD-16XDC
OD-16DDC
19-3040Bxx 25" Beige OD-16DXC 16 x 26 x 25 01, 02, 04, 05
19-3041Axx 34" Aluminum 0D-16DD 16 x 26 x 34 01, 02, 04, 05
19-3041Bxx 34" Beige OD-16DDC 16 x 26 x 34 01, 02, 04, 05
30" High Enclosures
19-3042Axx 25" Aluminum OD-30DX 30 x 26 x 25 01, 02, 04, 05 OD-30DXC
19-3042Bxx 25" Beige OD-30DXC 30 x 26 x 25 01, 02, 04, 05
19-3043Axx 34" Aluminum 0D-30DD 30 x 26 x 34 01, 02, 04, 05
19-3043Bxx 34" Beige OD-30DDC 30 x 26 x 34 01, 02, 04, 05
50" High Enclosures
19-3044Axx 25" Aluminum OD-50DX 50 x 26 x 25 01, 02, 03, 04, 05, 06 OD-50DXC
19-3044Bxx 25" Beige OD-50DXC 50 x 26 x 25 01, 02, 03, 04, 05, 06
19-3045Axx 34" Aluminum OD-50DD 50 x 26 x 34 01, 02, 03, 04, 05, 06
19-3045Bxx 34" Beige OD-50DDC 50 x 26 x 34 01, 02, 03, 04, 05, 06
19-3046Axx 42" Aluminum OD-50DDX 50 x 26 x 42 01, 03, 04, 06, 07
19-3046Bxx 42" Beige OD-50DDXC 50 x 26 x 42 01, 03, 04, 06, 07 also at top of page
62" High Enclosures
19-3047Axx 25" Aluminum OD-62DX 62 x 26 x 25 01, 02, 03, 04, 05, 06 OD-62DDC
19-3047Bxx 25" Beige OD-62DXC 62 x 26 x 25 01, 02, 03, 04, 05, 06
19-3048Axx 34" Aluminum OD-62DD 62 x 26 x 34 01, 02, 03, 04, 05, 06
19-3048Bxx 34" Beige OD-62DDC 62 x 26 x 34 01, 02, 03, 04, 05, 06
19-3049Axx 42" Aluminum OD-62DDX 62 x 26 x 42 01, 03, 04, 06, 07
19-3049Bxx 42" Beige OD-62DDXC 62 x 26 x 42 01, 03, 04, 06, 07
78" High Enclosures
19-3050Axx 25" Aluminum OD-78DX 78 x 26 x 25 01, 03, 04, 06, 07, 08 OD-78DXC
19-3050Bxx 25" Beige OD-78DXC 78 x 26 x 25 01, 03, 04, 06, 07, 08
19-3051Axx 34" Aluminum OD-78DD 78 x 26 x 34 01, 03, 04, 06, 07, 08
19-3051Bxx 34" Beige OD-78DDC 78 x 26 x 34 01, 03, 04, 06, 07, 08
19-3052Axx 42" Aluminum OD-78DDX 78 x 26 x 42 01, 03, 04, 07, 08
19-3052Bxx 42" Beige OD-78DDXC 78 x 26 x 42 01, 03, 04, 07, 08


ENCLOSURE BASIC OPTIONS GROUP
(see notes below) Note 1 Note 2 Note 3 Note 4 Note 5 Note 6 Note 7 Note 7 Note 7 Note 7
Connectronics Part Number > 19-3500 19-3530 19-3533 19-3505 19-3506 19-3509 19-3515 19-3517 19-3519 19-3522
Option  Group Dual
115VAC
Exhausting
Fans
with
Thermostat
Conduit-
Ready
4-Position
115AC Outlet
115-220VAC
60 Amp
load center
with 2
4-Position
115AC Outlets
115VAC
300W
Radiant
Heater
Fixed
Thermostat
115VAC
 600W
Radiant
Heater
Fixed
Thermostat
115VAC
400W
Heater
with Fan
Variable
Thermostat
115VAC
2400BTU/
400W
Heater
with Fan
Variable
Thermostat
115VAC
4000BTU/
400W
Heater
with Fan
Variable
Thermostat
115VAC
6000BTU/
400W
Heater
with Fan
Variable
Thermostat
220VAC
8000BTU/
400W
Heater
with Fan
Variable
Thermostat
Suffix General Descriptions
01 Basic 115VAC Exhausting
Fan out the top, with
adjustable thermostat
1 1
02 115VAC Exhausting Fan
w/ 300 Watt
Radiant Heater
1 1 1
03 115VAC Exhausting Fan
w/ 600 Watt
Radiant Heater
1 1 1
04 115VAC Exhausting fan
w/ 400 Watt Heater
with fan
1 1   1
05 115VAC Closed/Insulated w/
2400BTU Air Conditioner
& 400 Watt Heater
1   1
06 115VAC Closed/Insulated w/
4000BTU Air Conditioner
& 400 Watt Heater
1   1
07 115VAC Closed/Insulated w/
6000BTU Air Conditioner
& 400 Watt Heater
    1           1
08 220VAC Closed/Insulated w/
8000BTU Air Conditioner
& 400 Watt Heater
    1             1

Note 1:  Dual fan configuration brings air in via filtered vents and exhausts it out the top through bug protected mesh.
Note 2:  Attached to horizontal rail (adjustable position); customer must cut hole in exterior for conduit entry.
Note 3:  60 Amp load center has 8 circuit breaker positions (postions used:  2x 60 Amp input; 2x 20 Amp for outlets; 120 Amp for air conditioner).
Note 4:  300 Watt 115VAC Radiant heater has a fixed thermostat that turns on at 45°F and off at 55°F
Note 5:  600 Watt 115VAC Radiant heater has a fixed thermostat that turns on at 45°F and off at 55°F
Note 6:  Both fan and heater are controlled by variable thermostat (32°F to 140°F range)
Note 7:  Enclosures with air conditioners/heaters are fully insulated/closed system/non-vented-- fan runs continuously to circulate air.
                Standard exterior finish is painted beige.   Aluminum finish option to match enclosure finish is optional.

ACCESSORIES    •    ACCESSORIES    •    ACCESSORIES
Mounting Base Options mounting feet
Part no. Description
19-3552A 4" C-channel mounting feet, unpainted
•  Included quantity 2: 25" rails
•  Pre-drilled for all 26" W enclosures
Standard Open Base
•  3" high
•  For flat roof or soft ground application
19-3540A  For 26w" x 25" deep enclosures - Aluminum standard open base
19-3540B  For 26w" x 25" deep enclosures - Beige painted
19-3540A  For 26w" x 34" deep enclosures - Aluminum
19-3540B  For 26w" x 34" deep enclosures - Beige painted
19-3540B  For 26w" x 42" deep enclosures - Beige painted
Wrap-around Security Base
•  Prevents tampering with attachment bolts
19-3546A-3 For 26w" x 25" (DX) deep enclosures - 3" high, Aluminum                 wrap-around security base
19-3546B-3 For 26w" x 25" (DX) deep enclosures - 3" high,  Beige painted
19-3546B-12 For 26w" x 25" (DD) deep enclosures - 12" high,  Beige painted

19-3547A-3 For 26w" x 34" (DD) deep enclosures - 3" high,  Aluminum
19-3547A-3 For 26w" x 34" (DX) deep enclosures - 3" high,  Beige painted

19-3548A-3 For 26w" x 42" (DDX) deep enclosures - 3" high,  Aluminum
19-354A-3 For 26w" x 42" (DDX) deep enclosures - 3" high,  Beige painted
Exterior Mounting Shelf
19-3553A Aluminum exterior shelf•  Indoor /Outdoor

•  14"H x 30"W x 30"D

•  Maximum weight: 1750 lbs.
19-3553B Beige
19-3555A Lifting Eye-Hook Kit - set of 4, Aluminum Lifting Eye-Hookcastors

19-3555B Lifting Eye-Hook Kit - set of 4, Beige
19-3554 Heavy Duty Castor Kit -
set of 4, includes 2 locking and 2 standard

Electrical Options
19-3530 4-position (double gang) outlet box
• For 115VAC
• Conduit ready
• Mounts to internal horizontal rails

load centergenerator plug
19-3533 60 AMP / 8 position load center with 8 x 115VAC outlets
• 8 breaker positions (4 positions used)
• Includes two pre-wired, 4-position outlet boxes
• 220VAC ready
19-3535 Optional generator connection inlet plug
• Includes internal 220VAC breaker and mechanical interlock
• 50 AMP capacity (11,500 watt total)

Environmental Options
FANS - Dual
19-3500 Dual Exhausting Fan Kit, 115VAC, 220 CFM total
• Variable thermostat control
• Recommended for most non air-conditioned applications
exhaust fan



19-3501 Dual Exhausting Fan Kit, 115VAC, 220 CFM total, no thermosat
• For indoor application
19-3595 Dual Exhausting Fan Kit, 220VAC, 220 CFM total
• Variable thermostat control
19-3596 Dual Exhausting Fan Kit, 220VAC, 220 CFM total, no thermosat
• For indoor applications
19-3597 Dual Exhausting Fan Kit, 48VDC, 220 CFM total
• Variable thermostat control
19-3599 Dual Exhausting Fan Kit, 24VDC, 220 CFM total
• Variable thermostat control
19-3601 Dual Exhausting Fan Kit, 12VDC, 220 CFM total
• Variable thermostat control

FANS - Single
19-3503 Single Exhausting Fan Kit, 115VAC, 110 CFM total
• Variable thermostat control
• For 16" enclosures or low-heat equipment
exhaust fan
19-3504 Single Exhausting Fan Kit, 115VAC, 110 CFM total, no thermostat
• For indoor applications
19-3603 Single Exhausting Fan Kit, 220VAC, 110 CFM total
• Variable thermostat control
19-3604 Single Exhausting Fan Kit, 220VAC, 110 CFM total, no thermostat
• For indoor applications
19-3605 Single Exhausting Fan Kit, 48VDC, 110 CFM total
• Variable thermostat control
19-3607 Single Exhausting Fan Kit, 24VDC, 110 CFM total
• Variable thermostat control
19-3609 Single Exhausting Fan Kit, 12VDC, 110 CFM total
• Variable thermostat control
Fan Trays - 19" Rack Mount fan tray



air filter
19-3590 19" 3-fan tray, 330 CFM, 115 VAC, 6" deep
• Includes adjustable thermostat
• Reduces heat hot spots
19-3591 19" 6-fan tray, 660 CFM, 115 VAC, 17" deep       (shown)
• Includes adjustable thermostat
• Reduces heat hot spots
19-3593 Replacement Air Filter, washable (7-1/4" W x 10" H)
HEATERS
19-3505 300 Watt, 115VAC, Radiant Heater
• Fixed thermosat: 45°F on, 55° off
• 10.5" h x 6.5: w, mounts to rail
radiant heater




fan heater
19-3506 600 Watt, 115VAC, Radiant Heater
• Fixed thermosat: 45°F on, 55° off
• 20" h x 6.5: w, mounts to rail
19-3509 400 Watt, 115VAC, Fan Heater
• Variable thermostat control
• Fan distributes heat during operation


AIR CONDITIONER / HEATING OPTIONS Approx.
Max
Amps

19-3515 2400 BTU Air conditioner with 400 Watt heater, 115VAC 7.3 A

• Fully insulated / closed system
• Runs continuously to circulate air
• Beige painted exterior, aluminum finish option available
• Anti-corrosion option for coastal or industrial site applications
• Digital temperature controller (remote ethernet
   monitoring option) See PN 19-3618 below.

19-3517 4000 BTU Air conditioner with 400 Watt heater, 115VAC 8.6 A
19-3519 6000 BTU Air conditioner with 400 Watt heater, 115VAC 10.5 A
19-3521 8000 BTU Air conditioner with 400 Watt heater, 115VAC 13.7 A
19-3522 8000 BTU Air conditioner with 400 Watt heater, 220VAC 6.8 A
19-3524 10000 BTU Air conditioner with 400 Watt heater, 220VAC 7.8 A


Condition alarmClick to view
19-3526 12000 BTU Air conditioner with 400 Watt heater, 220VAC 8.6 A
19-3528 Exterior aluminum finish option (to match enclosure finish)
19-3527 Anti-corrosion option for coastal or industrial site applications
(required for NEMA 4X applications)

19-3617 Alarm condition dry contact relay output
• Includes Normally Closed (N.C.) and Normally Open (N O.) outputs

19-3618 Remote Ethernet Management/Reporting for air conditioners
• Monitor active enclosure temperature
• Remote control of air conditioner and heater settings
• Sends email messages periodically or on alarm conditions
• Includes local LCD display for complete on-site control
remote ethernet management/reporting Click to view

29-8148 5-Port Wide-temperature 10/100 Ethernet Switch
• -40°F to +75° F operation
• DIN rail mountable
• Requires 12VDC to 48VDC power supply
(ie. 15-6845, 18-5300, 82-6184, or 82-6411)
5 port ehternet switch

EXTRA RACK MOUNT RAILS
Part number Description enclosure rails
19-3560 19″ Rack Mount Rail Set for OD-16 Series, 9 RU, (16")
19-3561 19″ Rack Mount Rail Set for OD-30 Series, 16 RU, (30″)
19-3562 19″ Rack Mount Rail Set for OD-50 Series , 27 RU, (50″)
19-3563 19″ Rack Mount Rail Set for OD-62 Series , 34 RU , (62″)
19-3564 19″ Rack Mount Rail Set for OD-78 Series , 44 RU , (78″)
19-3565 23″ Rack Mount Rail Set for OD-30 Series, 16 RU , (30″)
19-3567 23″ Rack Mount Rail Set for OD-50 Series, 27 RU , (50″)
19-3568 23″ Rack Mount Rail Set for OD-62 Series, 34 RU , (62″)
19-3569 23″ Rack Mount Rail Set for OD-78 Series, 44 RU , (78″)
SHELVES
Inside Mounting Trays (beige)
19-3576 12" Deep Mounting Tray
•  requires double 19" rack mounting
Mounts to 19"
rack rails
at front and rear
enclosure shelf
19-3577 20" Deep Mounting Tray
•  requires double 19" rack mounting
19-3578 29" Deep Mounting Tray
•  requires double 19" rack mounting
19-3579 37" Deep Mounting Tray
•  requires double 19" rack mounting

19-3580 17" Deep single 19" rack mounting tray, beige
• Adjustable for forward or rear placement
  enclosure tray
Heavy Duty Battery Tray Shelves
19-3581 17" wide x 16" deep, beige -Requires single 19" rack mounting
enclosure battery tray
19-3582 17" wide x 16" deep, beige - Requires single 23" rack mounting
19-3583 17" wide x 21" deep, beige - Requires single 19" rack mounting
19-3584 17" wide x 21" deep, beige - Requires single 23" rack mounting
19-3585 21" wide x 21" deep, beige - Requires single 23" rack mounting
Side Mount Boxes
19-3010SMB Small side mount box for cable entry Side Mount Box
  •  14"H x 12"W x 7" D
•  For protected cable entry
•  Beige
19-3013SMB Medium side mount box for cable entry
  •  24"H x 16"W x 8" D
•  For protected cable entry
•  Beige
19-3014SMB Large side mount box for cable entry
  •  26"H x 22"W x 10" D
•  For protected cable entry
•  Beige

Fully-Configuired Wireless/Wimax/LTE Enclosures
19-3055 Fully-Configured Wireless Enclosure - fan cooled Wireless enclosureWireless enclosure with air conditioning
• 78"H x 25"W x 34"D, painted white
• Direct air cooled
• Specify AC or DC input voltage
• Separate battery compartment (25.69"H)
• Large side mount cable entry box (45"H x 26" W x 10"D)
19-3056 Fully-Configured Wireless Enclosure - with air conditioner
  • 78"H x 25"W x 34"D, painted white
• 220VAC 6000BTU air conditioner & 400 Watt heater
• Separate battery compartment (25.69"H)
• Large side mount cable entry box (45"H x 26" W x 10"D)
• See PN 19-3618 for remote Ethernet monitoring option
  19-3055                       19-3056
view slide show
